Mold Bases

Create, Edit and Draw DME USA catalogue mold bases

With types A, B, AX, T, X5 and X6 bases configurations.

All dimensions options and inserted components included

'K' Series mold bases metric catalogue

All series' available configurations and dimensions included.

Custom mold bases in inches or millimeters

Custom number of plates, plates' configuration and dimensions

Dialog boxes' information on How-To commands' name reference

Comprehensive parametric library of mold components available in both inches and millimeters

Components are created and drawn at insertion as Acad native 3D Solid objects

Programable plates' clearances, offsets, threads, gaps are also drawn at insertion

Fully representation of threads on components and affected insertion objects

Copy and delete component functions

Delete function will delete component, clearances and other insertion parameters

Dialog boxes' information on How-To commands' name reference

Easily design water circuits by drawing with lines the water paths

Separate objects where water lines are going to be created

Open the function dialog box and select line's geometry and diameter

By selecting the object and lines the circuits will be created by subtraction

Dialog box select pressure plug insertion options

Pressure plugs will be automatically created following functions prompts

Easily create lateral threaded holes in inches or millimeters

Table configuration to set title, headers included or excluded, header's order and text, and table and text styles

Edit table to define the description on any mold object. Also used to registered any other mold object not created by the program

Insert table command to represent the BOM table in the drawing

MT_SUBTRACT a modified version of the Acad SUBTRACT command

Selecting first the object where to subtract from and then the objects to subtract

The command restores all the subtracted object properties and offers the option of keeping the subtracted forms for a future use

Show drop down menu to show/hide mold objects

Full mold sides objects, 'B'

or 'A'

Separate mold plates assemblies

and mold components

or full assemblies of selected components and plates

Please feel free to contact us :
